Expertise
Testing
HV | LV Testing
Get Our Dedicated Teams For Your Most Complex Systems
SESC offer a complete solution for your HV, LV systems that begins with the testing and commissioning plan and ends with the successful start up load testing of all system.
Whether it's Factory Acceptance Testing (FAT), Site Acceptance Testing (SAT), Phased commissioning or loads testing our expert engineers have the skills and experience to commission even your most complex systems. We use our extensive library of Inspection and Test Plans, Procedures, Test Verification documents, and Method Statements to document all activities and provide you independent verification of our systems readiness for handover.
We provide our clients with a comprehensive testing and commissioning service on a wide range of HV, LV system assets including power transformers, current & voltage transformers, circuit breakers, switchgear, protection relays, revenue meters, earthing systems, cables etc.
Development of commissioning plans, procedures and verification documents for projects and to provide recommendations if necessary.
"We only work above and beyond expectation"
Whatever The Scale, And No Matter The Complexity, We Have You Covered
Power System Scheme Tests
-
Transformer through tests to check transformer protection stability
-
Bus Zone primary injection to check stability
HV Switchgear
-
Insulation Resistance Tests
-
Power frequency Dielectric Withstand Test
-
Contact Resistance Test
-
Circuit Breaker Contacts Static and Dynamic Timing Test
-
Pickup and Drop out tests on Under Voltage and Shunt Trip Coils
-
Interlock and Function Checks
High Voltage & Low Voltage Switchboards
-
Functional tests, Interlocks etc.
-
Online and Offline Partial Discharge testing
LV Switchgear
-
Insulation Resistance Test
-
Contact Resistance Test
-
Interlock and Function Checks
-
Trip Unit
-
Pickup and Drop out tests
-
Timing tests
-
DC Power Systems
-
Commission Battery systems
-
Load Tests on Battery Banks
Earth Systems
-
Soil Resistivity
-
Earth Grid Impedance
-
Step & Touch Potential Tests
DC Power Systems
-
Functional tests, Interlocks etc.
-
Online and Offline Partial Discharge testing
Voltage Transformers (HV & LV)
-
Ratios, Polarity, Winding Resistance, IR & PI
-
Dielectric Loss Angle
-
Partial Discharge (Online & Offline)
Current Transformers (HV & LV)
-
Ratios, Polarity, Magnetisation Curves, Winding Resistance, IR & PI
-
Dielectric Loss Angle
-
Partial Discharge (Online & Offline)
High Voltage & Low Voltage Switchboards
-
Functional tests, Interlocks etc.
-
Online and Offline Partial Discharge testing
Power Transformers
-
Insulation Resistance
-
Vector Group and Polarisation Index Tests
-
Dynamic Resistance
-
HV and LV Winding Resistance Tests
-
No Load Voltage Ratio (Transformer Turns Ratio) Test
-
Tan Delta Test
-
Short Circuit Test
-
Excitation Current
-
Leakage Reactance/Impedance
-
Partial Discharge (Online & Offline)
-
Dielectric Response Analysis (DIRANA) Test
-
Sweep Frequency Response Analysis (SFRA) Test
-
Dissolved Gas Analysis and Furan Analysis for Transformers
Protection Relays
-
Pickup and Drop Out tests
-
Timing test by Primary and/or Secondary Injection
High Voltage & Low Voltage Circuit Breakers
-
Insulation Resistance
-
Power Frequency Dielectric Withstand Test
-
Polarisation Index
-
Contact Resistance
-
Static & Dynamic
-
-
Contact Timing
-
Dielectric Loss Angle
-
Partial Discharge
-
Online & Offline
-
-
On-board Protection Relays
-
Set up
-
Primary & Secondary injection
-
HV Cables
-
Very Low Frequency (VLF) Withstand Test
-
Sheath Integrity Test
-
Tan Delta Test
-
Insulation Resistance (IR)
-
Polarisation Index (PI)
-
Partial Discharge (Online & Off Line)
